An On-grid solar system will only work till grid power is present. In case of a power cut or grid failure, your PV system will automatically shut down.
This occurs due to a safety feature called anti-islanding. Shutting down the system ensures that your generated energy does not pose any risk to the maintenance personnel that are working on the grid.
But frequent shutdowns can affect your solar ROI. Luckily, there is a way around this problem! You can use your diesel generator to start your on-grid system.
However, you will need a DG PV Synchronization device to do this. Let’s understand why.
What is DG PV Synchronization?
On-Grid inverters require reference voltage from the grid. However, one can use a diesel generator to provide this reference in the absence of the grid. But there are some stipulations.
- Unlike grids, you cannot add your surplus solar energy into the generator because it is not built to receive power. Back-feeding energy in a generator can not only damage the device but also pose a fire risk.
- For optimum functioning and maximum fuel savings, a generator has to run up to at least 30% of its capacity. For example, if your Diesel generator has a capacity of 100kW, then it has to power a minimum load capacity of 30kW.
This is where a DG-PV Synchronizer comes in!
This smart device communicates both with the Diesel generator and solar inverter to power your PV system even during blackouts.
The synchronizer will make sure that generator runs up to 30% of its capacity. Once that requirement is fulfilled, it will instruct the PV system to start generation.
Moreover, if the solar system produces excess power, the device will limit production and ensure that no electricity is being fed to the DG. This is why the DG PV Synchronizer is also called a zero export device.
Example:
If DG Capacity is 100kW and your demand is also 100kW. The DG PV device will ensure 30 kW demand is met through DG and the rest 70 kW through solar panels.
Benefits:
1. You can use your on-grid solar system even during blackouts.
2. Since only a small portion of demand is met through DG, you end up saving fuel.
3. If solar generation does down, the device will raise DG power to meet demand. This results in a reliable power supply.
Can a Low Capacity DG be Used for Reference?
Many assume that since a Diesel generator is just there for reference, you can buy a low-capacity diesel generator for the job. But we do not recommend it.
Solar works best as a secondary source of power. This is because your generation can fall due to external circumstances such as cloud cover, rain, etc. But your diesel generator can compensate for this shortfall.
Thus, it is always advisable to invest in a DG that matches your load capacity.
Where Can You Buy a DG PV Synchronizer?
For the most reliable device, opt for Ornate Solar’s advanced DG PV Synchronization Device, Vyasa. This intelligent controller is powered by edge computing and can be seamlessly integrated with all types of solar inverters and diesel generators. We can also customize the device to allow multiple DG connections.
Vyasa stays online at all times. This allows a quick switch from grid power to DG power. It is efficient, low maintenance, and reduces fuel consumption.
About Ornate Solar
Ornate Solar is a leading solar company with 8+ years of experience in the industry and the mission to reimagine the way solar is installed worldwide.
From advanced solar panels, innovative inverter solutions, and high-quality accessories to the unique InRoof that turns panels into the primary roof, we develop and deliver solutions that are modern, reliable, and effective.
If you are exploring DG PV Synchronizers, reach out to us at 011 43536666 to discuss your options. Ornate Solar’s dedicated technical team will handle the complete installation process for you.
